Fram (Nansen)

Postby shipstamps » Sat Dec 27, 2008 11:19 am

SG392
Click image to view full size
Click image to view full size
Click image to view full size
SG1034
Click image to view full size
SG348
Click image to view full size
SG46
Click image to view full size
SG518
Click image to view full size
SG691
Click image to view full size
SG2658
Click image to view full size
SG34
Click image to view full size
Click image to view full size
IN 1890 when the Norwegian Parliament, the Storthing, agreed to aid Nansen, he made arrangements with Mr. Colin Archer, a British-born resident in Larvik, to construct a suitable vessel for work in Arctic waters. After several models had been submitted to Nansen he chose a design, and work commenced. At the expiration of two years the immortal Fram, was ready for sea. She was the strongest vessel of her size which had ever been built for work in the Arctic. Launched at Larvik, on October 26, 1892, she was christened by Mrs. Nansen. The vessel had an ungainly look; the after part of her flush deck sloped upwards to give more head room and the masts were so thick that it was thought in the shipyard she might be top-heavy. She was built just large enough to carry provisions for 13 or 14 men for six years, besides the necessary fuel and equipment. Her displacement was close on 600 tons and she had machinery of 160 i.h.p., which gave her a speed of six knots, on a coal consumption of 2 3/4 tons per day.
Pointed at stem and stern she resembled a Scots "buckie" boat, excepting that she was carvel-built, and was almost flat-bottomed so that she could rest on the ice, if necessary, without capsizing. Both the stem and stern were considerably curved to prevent the ice gripping the ship. Her screw could be raised when necessary and was protected from damage in a well; the rudder was also similarly adapted for this purpose. The ship's sides (from 28 in. to 32 in thick,) were solidly constructed of oak, pitchpine and greenheart, and were strengthened by many beams and stays inside the vessel, while the whole ship was divided into three sections by two watertight wooden bulkheads. On her foremast the Fram carried a square foresail and topsail, and was fore and aft rigged on main and mizzenmasts; her sail area was about 650 sq. yds. Her principal dimensions were; Overall length, 128 ft.; beam (excluding ice sheathing), 36 ft; moulded depth, 17 ft; draft with light cargo, 12 ft; freeboard, with full load, 3 V2 ft.
Nansen believed in bright, cheerful colours, and the Fram 's hull above the waterline was painted grey, the gunwale green, the poop scarlet, while red, white and green were the prevailing colours of the deck fittings. The whole expedition was fitted out most thoroughly—over £25,000 was expended upon the ship and her outfit, the vessel alone costing nearly £10,000. She is depicted on the first two stamps, with her two great navigators, Nansen and later Amundsen. She left Norway on June 24, 1893, and reached 85 deg. N., the farthest North any ship had been up to that time, and returned to Norway in 1896. In 1899 she was used by Sverdrup in his exploration of Jones Sound (Baffin Bay).
In 1910 Capt. Roald Amundsen used the Fram for his famous voyage to the South Pole, after she had been converted from steam to oil firing. The vessel is now on public view at the Bygdones Museum, Oslo, where she is being preserved for posterity by the Norwegian Government.
Norway SG392
shipstamps
Site Admin

Posts: 0
Joined: Fri Mar 13, 2009 8:12 pm

Re: Fram (Nansen)

Postby aukepalmhof » Tue Dec 13, 2011 3:06 am

Click image to view full size
Click image to view full size
Click image to view full size
Click image to view full size
Click image to view full size
Scan 3.jpeg
Click image to view full size
1980 fram.jpg
Click image to view full size
2012 fram.jpg
Click image to view full size
2011 fram.jpg
Click image to view full size
2016 fram icebreaker.jpg
Click image to view full size
On 14 December 1911, five men stood at the southern axis of the earth. They planted the Norwegian flag and named the area KongHaakon VIIs vidde. Those men were Roald Amundsen, Olav Bjaaland, Oscar Wisting, Helmer Hansen and Sverre Hassel, the first men to reach the South Pole.
They had left the Framheim base on 20 October, taking with them four sledges and 52 dogs. The dogs were one of the most important items Amundsen had with him. He had brought them from Greenland, because the underfoot conditions and terrain were ideal for Eskimo dogs. Amundsen also recognized the advantage of being able to slaughter the weaker dogs en route and use the meat to feed the others. As it turned out, the human members of the expedition also appreciated a fresh piece of canine steak.
The going was tough at times; the cold was severe and the conditions were bad. However, the final days of their journey were better and the weather could not have been more perfect for their arrival at the South Pole. At three o’clock in the afternoon of 14 December, the sledge drivers called a halt. They had been checking their distance-measuring wheels continuously and had now covered the calculated distance. They were probably not at the exact location of the Pole. It would have been impossible for them to calculate that with the instruments they had, but as Amundsen was to write later they were so close that the few possible kilometres of separation could make no difference whatsoever.
After encircling their camping site, they commenced the formal act of planting the flag. Amundsen had decided that all five members were to participate. Five calloused, frostbitten fists took a firm grip of the pole, lifted up the waving flag and planted it. Thanks to Bjaaland, photographs were taken at the South Pole. Amundsen’s expensive camera had been damaged, but Bjaaland with his simple Kodak camera and his often random photos of the moment ensured that the expedition was photographically documented.
They arrived back at Framheim on 25 January 1912. They had been away for 99 days and had covered a distance of about 3000 kilometres.
Norway 2011 14.00 and 17.00 Kr. Sg?, scott”
Source: Norway Post

60c - Roald Amundsen
A skilled explorer and well known for his meticulous planning, Amundsen set his sights on the South Pole when he heard of Scott’s forthcoming Antarctic expedition. He departed Norway on 9 August 1910 aboard the ship Fram, at which time his destination was known only to his most trusted officers.
Ross Dependency 2011 60c sg?, scott?
http://stamps.nzpost.co.nz/ross-depende ... /race-pole

Bulgaria 2011 1.00 lev, sg?, scott?
North Korea 1980 sgN1963, scott?
Sierra Leone 2016 LE6000 sg?, scott?
Last edited by aukepalmhof on Tue Feb 14, 2017 8:09 pm, edited 4 times in total.
aukepalmhof

Posts: 6604
Joined: Thu Apr 02, 2009 1:28 am

Re: Fram (Nansen)

Postby aukepalmhof » Fri Mar 07, 2014 2:49 am

2011 fram1.jpg
Click image to view full size
2001 fram.jpg
Click image to view full size
2011  Fram-.JPG
Click image to view full size
1979 fram.jpg
Click image to view full size
1977 fram.jpg
Click image to view full size
2007  Fram.jpg
Click image to view full size
2011  Fram 1.JPG
Click image to view full size
2011 fram pmk.jpg
Click image to view full size
2011 Fram.gif
Click image to view full size
Mozambique 2011 175.00MT sg?, scott?
Romania 2001 postcard
Guinea 2011 45000 FG sgMS?, scott?
1977 Norway cinderella
1979 Australian Antarctic Terr. FDG.
2007 Guinea-Bissau 3000 fcfa sgMS?, scott?
2011 Togo 750F sgMS?, scott?
2011 Togo 3000F sgMS?, scott?
2011 Togo 750F sgMS?, scott?
2011 Germany postmark. All images were supplied by Mr Gennadiy Sitnikov.)
Last edited by aukepalmhof on Sun Mar 09, 2014 3:44 am, edited 2 times in total.
aukepalmhof

Posts: 6604
Joined: Thu Apr 02, 2009 1:28 am

Re: Fram (Nansen)

Postby Arturo » Fri Mar 14, 2014 7:23 pm

Click image to view full size
Fram (Nansen)

Umm Al Qiwain, 1972.
Arturo

Posts: 723
Joined: Mon Feb 13, 2012 8:11 pm

Re: Fram (Nansen)

Postby aukepalmhof » Sun Jan 05, 2020 8:51 pm

2018 fram ms.jpg
Click image to view full size
2018 fram (2).jpg
Click image to view full size
St Tome et Principe 2018 Db 31.00 sg?, scott? and Db 12.400 sgMS?, scott? (In the MS the fram is depict in the background of the margin.
aukepalmhof

Posts: 6604
Joined: Thu Apr 02, 2009 1:28 am
